Кабель EV CHARGING 5M 32A DK-3P32-S-050 ASSMANN

DIGITUS Spiral EV charging cable, 5 m, type 2 to type 2Product number: DK-3P32-S-050
EAN: 4016032481539
EV charging - Three Phase, 400 V, 32 A, 5 m Type 2 to Type 2 Spiral charger cable
DIGITUS DK-3P32-S-050 (5 m) high quality flexible cable, offers in longer length, the comfort of charging in Home (garage) and also in public charging station

• The EV charging cable from DIGITUS is compatible with all electric vehicles (EV) and plug-in hybrid vehicles (PHEV) that have a CCS or Type 2 charging connection and can be charged with alternating current
• Three-phase charging cables for max. 22 kW/32 A are compatible with all common alternating current charging stations – Short cables are ideal if charging is always carried out at the same charging point and the length is sufficient
• For charging outdoors, the charging cable complies with protection class IP55 (water jet-proof), which means that a secure connection is possible between charging station and charging socket (charging inlet)
• Spiral cables draw together on their own and remain clean for longer compared to straight vehicle charging cables, since they do not hang down to the ground or only hang down partially when charging the vehicle battery
• Thanks to IEC type 2 plug and jack (EU standard IEC 62196-2), the mode 3 cable can be used at nearly any charging station and wallbox in Europe to charge electric cars and other electric vehicles

DESCRIPTIONThe DIGITUS DK-3P32-S-050 car charging cable allows you to easily connect any vehicle with type 2 plug to public charging stations or wallboxes with charging socket. The type 2 charging cables are certified according to EN 62196-1:2014, EN 62196-2:2017 and protection class IP55.
TECHNICAL DETAILS

• Type: Spiral cable
• Length: 5 m
• Charging cable type: 5 x 6 mm² + 2 x 0,5 mm²
• Jacket: TPU
• Connector: EN 62196-2 Type 2
• Rated voltage: 400 V
• Rated power: 22 kW
• Rated current: 32 A
• Connection phases: 3
• Operating temperature: -30℃～+50℃
• Protection class: IP55 (water-jet protected)
